P5 Connector

P5 connects a single 3.5" floppy drive. Power for this drive is supplied by the connector.
5-6
Table 5-5 XVME-973/1 P5 Connector Pinout
Pin Signal
1 +5V
2 IDX*
3 +5V
4 FDS1*
5 +5V
6 DCHG*
7 NC
8 NC
9 NC
10 MO1*
11 NC
12 FDIRC*
13 NC
Pin Signal
14 FSTEP*
15 GND
16 FWD*
17 GND
18 FWE*
19 GND
20 FTKO*
21 GND
22 FWP*
23 GND
24 FRDD*
25 GND
26 FHS*
