Chapter 1 – Introduction
The XVME-653 VMEbus Pentium
and the XVME-658 VMEbus AMD-K6
are designed to combine the high performance and ruggedized packaging of the VMEbus
with the broad application software base of the IBM PC standard. These modules inte-
grate the latest processor and chipset technology.
At the core of the XVME-653 is an Intel
ogy. This generation of Pentium processors features enhanced multimedia instructions,
larger level 1 caches, and a 10 to 20 percent performance increase over standard Pentium
processors.
At the core of the XVME-658 is an AMD 333 MHz K6-2 CPU with 3DNOW!™ Tech-
nology. 3DNOW!™ Technology is the first innovation to the x86 processor architecture
that significantly enhances floating-point-intensive three-dimensional (3D) graphics per-
formance. The AMD-K6-2 system can provide performance comparable to the many of
the Pentium II systems on the market today.

Module Features

The XVME-653 and the XVME-658 offer the following features:
•
233 MHz Intel Pentium MMX CPU (XVME-653)
•
333 MHz AMD-K6-2 CPU with 3DNOW! Technology (XVME-658)
•
Up to 256 MB fast-page or EDO DRAM in 72-pin SIMM sites, with ECC or parity
•
512 KB of synchronous level 2 pipeline cache
•
High-performance PCI local bus SVGA controller with 2 MB of VRAM
•
PCI Enhanced IDE controller with DMA
•
10/100 Mbit PCI Ethernet controller with front RJ-45 connector
•
32-pin site for DiskOnChip or battery-backed SRAM
•
PCI-to-VMEbus interface with DMA
•
Two high-speed 16550-compatible serial ports
•
One Universal Serial Bus (USB) port
•
EPP or ECP configurable parallel port
•
PS/2-style keyboard and mouse ports
•
Configurable hardware byte-swapping logic (XVME-658 and XVME-653/31x)
•
Expansion options for PC/104, PMC, ISA, and PCI cards
®
MMX™ PC-compatible VMEbus processor module
®
-2 PC-compatible VMEbus processor module
®
233 MHz Pentium CPU with MMX technol-
1-1
