P3 Connector

P3 connects a single 3.5" floppy drive. Only one drive is supported. Power for this drive
is not supplied by the XVME-973/1.
5-4
Table 5-3 XVME-973/1 P3 Connector Pinout
Pin Signal
1 GND
2 FRWC*
3 GND
4 NC
5 KEY (NC)
6 NC
7 GND
8 IDX*
9 GND
10 MO1*
11 GND
12 NC
13 GND
14 FDS1*
15 GND
16 NC
17 GND
Pin Signal
18 FDIRC*
19 GND
20 FSTEP*
21 GND
22 FWD*
23 GND
24 FWE*
25 GND
26 FTK0*
27 GND
28 FWP*
29 GND
30 FRDD*
31 GND
32 FHS*
33 GND
34 DCHG*
