Global Configurator
Use the Global Configurator software to set up and configure the control processor and the
TLI Pro 101. See the Global Configurator Plus and Global Configurator Professional Help File
for step-by-step instructions and more detailed information. The Global Configurator Plus and
Global Configurator Professional Help File also includes an introduction to the software and
sections on how to start and configure a project.

TLI Pro 101 Web Page

To access the TLI Pro 101 default web page, enter the IP address of the unit into the web
browser of a PC connected to the same subnet.
A dialog opens asking for your user name and password. By default, the user name is
and the password is
The single page provides general and network information about the unit. It also allows you to
upgrade the unit firmware.
Use the
the network settings of the TLI Pro 101.
Extron Electronics
Figure 20.
(both user name and password are all lower case).
extron
Setup Menu (see page 13) or the Toolbelt feature of Global Configurator to configure
®
General Status
Model Name: TLI Pro 101
Description: TouchLink Pro Interface
Part Number: 60-1083-01
Firmware Version: 1.00
Date: Monday, May 27, 2013
Time: 7:58 PM
POE: On
Up Time: 0 day(s) 1 hour(s) 23 minute(s)
License Information
System Devices
Device Name
Firmware Upgrades
Firmware:
TLI Pro 101 Web Page
IP
DHCP: Off
Host Name: TLI-Pro-101-0B-37-38
IPv4 IP Address: 192-168-254-251
DNS (IP): 127.0.0.1
Gateway IP: 0.0.0.0
Subnet Mask: 255.255.255.0
Mac Address: 00-05-A6-XX-XX-XX
Part Number
Browse Upload
TLI Pro 101 • Internal Web Pages
admin
Project
No Project Configured
Hostname/IP
