6.
Set up the interface for Network Communication:
Connect the PC that you will use for setup, the control processor, and the TLI Pro 101
…
to the same Ethernet subnetwork.
Setup Menu
Use the
…
Professional and Global Configurator Plus to set the DHCP status and, if necessary,
the IP address, subnet mask, gateway, and related settings for the interface.
7. Configure the Interface — the Global Configurator Professional and Global Configurator
Plus Help File and the GUI Designer Help File provide step-by-step instructions and
detailed information.
The Global Configurator Professional and Global Configurator Plus Help File
includes an introduction to the software and sections on how to start a project and
configuration.
(see page 13) or the Toolbelt feature of Global Configurator
TLI Pro 101 • Installation Overview 4
