3.
If DHCP is disabled, set the unit IP address, subnet mask, gateway address, and DNS
server address.
a. Press the button for the address to be edited. A screen opens, showing the address
and a numerical keypad.
Figure 9.
Numeric Pad for Setting IP Addresses
b.
Press Clear to remove the old address.
c. Press any octet button to highlight and start editing it.
d.
Enter the 3-digit value for that octet (leading zeroes in an octet are ignored).
NOTE:
Octets can have any value between
an invalid number, for example
cannot be entered.
to delete the last digit. If no value has been entered for the selected
Press
Back
octet, clicking
Back
last digit of that octet.
e.
Press the next octet button and enter a value.
f. Repeat steps c-e until values have been entered for all four octets.
g. Press to save the changes and return to the
OK
return to the Network screen without saving the changes.
4. If you have changed any of the values in the
background color of the button changes to blue. Press
apply the new values or press
changes. The button returns to gray.
If you have not made any changes, the
0
, you are able to enter the
892
moves the cursor back to the previous octet and deletes the
Network
Network
to return to the previous values without saving the
Revert
and
Apply Revert
TLI Pro 101 • On-screen Menus
