Epygi Manual III User Manual page 41

The table displayed here lists destinations where the incoming call from a particular caller will be ringing in the configured sequence.
The Enable/Disable functional buttons are used to enable or
disable ringing on the destinations in the Find Me/Follow Me
table.
The Ring Extension Phone drop down list is used to select the
interval in which the current extension (on which you are
currently configuring the Find Me/Follow Me service) will ring
on the incoming call from the selected caller. With the
Immediately selection, the current extension will ring
immediately as the call comes in.
The Max Active Calls Count text field requires the maximum
number of active calls.
If N= 1, where N is the maximum number of active calls, then only
one active call will be possible to make and the next call will go to
the voice mail. If N >1, then the next call will go to the next Find
Me/Follow Me phones (if configured) which are not in the call.
The Confirmation Passcode text field requires the password to
accept the call for destinations where passcode activation is
enabled (see below). Only digit values are allowed in this text
field.
Add opens the Add Entry page to add a destination to the Find
Me/Follow Me table. It consists of the following components:
Call Type lists the available call types:
PBX - destination is a local QX IP PBX extensions or Auto
Attendant.
•
SIP –destination is reached through a SIP server.
PSTN –destination is a PSTN user.
•
Auto – used for undefined call types. In this case, routing
•
pattern will be considered here and passed through Call
•
Routing Table.
The Address text field requires the SIP address (see chapter
the certain caller will be ringing. If the address already exists in the table, selecting Save will display the error "Caller address already exists". A wildcard is
allowed in this field (see chapter
type. The PSTN number length depends on the area code and phone number.
The Start Ringing drop down list is used to select the interval when the destination will ring after the call from the selected caller comes in to the current
extension. Immediately selection indicates that the destination will ring immediately as the call comes in.
The Ask Confirmation Passcode checkbox is used to enable the password protection of the call. With this option enabled, the destination who answers
the call will be prompted to insert a password in order to accept the call. The confirmation passcode is defined under the Find Me/Follow Me table (see
above).
Welcome Message - this group allows specifying the Find Me/Follow Me Welcome Message Delay and updating the welcome message which is playing
only once when calling to Find Me/Follow Me extension, downloading it to the PC, or restoring the default one.
The group offers the following components:
QX50/QX200/QX2000; (SW Version 6.0.x)
Entering SIP Addresses
Entering SIP Addresses Correctly). The extension number should be inserted into the Address text field for the PBX call
QX50/QX200/QX2000 Manual III: Extension User's Guide
Fig.III- 35: Find Me/Follow Me – Add Entry page
Correctly), extension or PSTN number, where the incoming call from
Fig.III- 34: Find Me/Follow Me page
41
