The Calling Code (#) requires a key combination to dial the destination phone number. Only numeric characters are allowed for this field. If nonnumeric

symbols are entered and the Save button is selected, "Incorrect calling code: no symbol characters allowed" will appear. This field is limited to two digits.

If the calling code already exists in the Speed Calling Codes table, the "Speed Calling Code already exists" error will appear when you select Save.

Description allows entering a short description about the called destination or simply the username of the remote party.

Depending on the selected call type the Call To text field requires the SIP address, extension or PSTN number that has to be dialed whenever the calling

code is used. The extension number should be inserted in the Call To field for the PBX call type. A SIP address should be entered for SIP call type. Only SIP

registration username can be inserted here to call to the SIP user registered on the same SIP server that the current extension is registered on. If the SIP

server hostname is omitted, the system will automatically set the current extension's registration server hostname instead. A PSTN number should be

inserted for PSTN call type. The PSTN number length depends on the area code and phone number. For the PSTN call type, the symbols ",", "p" and "P" are

available to be inserted in this field. These symbols are used to insert a 1 second long pause which might be required by the PSTN dialing rules.

Press the Add button on the Speed Calling Settings page. The Speed Calling Settings - Add Entry page will appear in the browser window.

To Add a Speed Calling Code

Select the call type from the Call Type drop down list.

Choose a Calling Code and enter the Description for the called party.

Enter the destination SIP address, extension or PSTN number (dependant on the chosen call type) in the Call To text field according to the entering

rules.

To create the Speed Calling Code click on Save.

Select the checkbox of the corresponding record that has to is be edited in the Speed Calling Codes table

To Edit a Speed Calling Code

Press the Edit button on the Speed Calling Settings page. The Speed Calling Settings-Edit Entry page will appear in the browser window.

Change the desired fields.

To save the modifications click on Save.

Select the checkbox of the corresponding record that should to be deleted from the Speed Calling Code table.

To Delete a Speed Calling Code

Press the Delete button on the Speed Calling page.

Confirm the deletion by clicking the Yes button. The speed calling code with its parameters will be deleted. To abort the deletion and to keep the

original record in the list, select No.

Account Settings

The Account Settings page provides information on the extension display name, allows changing the user password, enabling user password protection

for incoming/outgoing calls and downloading/uploading of a file with the user-defined voice greetings. All parameters listed on this page may be modified

and submitted. This page consists of the following components:

Extension shows a non-editable parameter providing

information about the current user extension number.

Display Name defines an optional parameter used to identify

the caller. Usually the display name appears on the phone

display if a call is placed or a voice mail is sent. The field is not

limited regarding symbol usage but its length is limited to

twenty characters.

Incoming Calls enables password protection for

Password Protection for:

incoming calls. If the service is enabled a user password

•
