Your Extension Graphical Interface

QX IP PBX configuration management may be accessed on two different levels: for users (extensions) and administrators. If you are an extension user, log
in with the extension number and the password (if any) you received from your system administrator.
If you are an admin, additionally the Return link will appear to go back to the QX Management page.
Log Out is used to close the session between the user PC and QX and to leave the QX Your Extension Management.
Your Extension menus allow you to access the following settings to operate and perform actions that are private for each user:
Voice Mail
•
•
•
•
Call History
PBX Information
Speed Calling
Account Settings
Basic Services
•
•
•
•

Entering SIP Addresses Correctly

Calls over IP are implemented based on Session Initiating Protocol (SIP) on the QX IP PBX. When making a call to a destination that is somewhere on the
Internet, a SIP address must be provided.
SIP addresses needs to be specified in one of the following formats:
"display name" <username@ipaddress:port>
"display name" <username@ipaddress>
username@ipaddress:port
username@ipaddress
username
For your convenience, the following combinations can be used:
*@ipaddress - any user from the specified SIP server
username@* - a specified user from any SIP server
•
*@* - any user from any SIP server
•
•
QX50/QX200/QX2000; (SW Version 6.0.x)
Voice Mailbox
Voice Mail Settings
Voice Mail Profiles
Group List
General Settings
Hold Music Settings
Do Not Disturb
Hot Line Settings
QX50/QX200/QX2000 Manual III: Extension User's Guide
Hiding Caller Information
Caller ID Services
Incoming Call Blocking
•
Outgoing Call Blocking
•
Distinctive Ringing
•
Call Hunting
•
Many Extensions Ringing
•
Unconditional Call Forwarding
•
Busy Call Forwarding
•
No Answer Call Forwarding
•
Unregistered/Inaccessible Call Forwarding
•
Find Me / Follow Me
•
Emergency Interrupt
•
Intercom
•
Voicemail Profile
•
•
The display name and the port number are optional parameters in the SIP
address. If a port is not specified, 5060 will be set up as the default one. The
range of valid ports is between 1024 and 65536.
A flexible structure of wildcards is allowed. In comparison with a wildcard,
the "?" character stands for only one unknown digit and the "*" character
stands for any number of any digits.
Wildcards are available for caller addresses only. No wildcard
characters are allowed for called party addresses. Exceptions are addresses
Please Note:
in the Caller ID Services - Addresses table that are used by Outgoing Call
Blocking and Hiding Caller Information Settings services. To use "*" and
"?" alone (as non wildcard characters), use "\*" and "\?" correspondingly.
