When clicking on the Address in the Caller ID Based Services table, the caller ID based services configuration pages for the corresponding extension will
be displayed.
The Caller ID Based Services for Address page consists of two frames. In the left frame all caller ID based services are listed. Clicking on the
corresponding caller ID based service, its settings will be displayed in the right frame.
Remember to save changes before moving between the caller ID based services configuration pages.
Please Note:
Below are the instructions to configure each caller ID based service available to the user.
To Configure Caller ID Based Services
Press the Add button on the Caller ID Based Services page. The Caller ID Based Services - Add Entry page, where new addresses can be defined,
will appear in the browser window.
1.
Define an optional Description of the address.
Select the call type from the Call Type drop down list.
2.
Enter the SIP address, extension or PSTN number (dependant on the chosen call type) in the Address text field according to the entering rules.
3.
Select the Presence State of an extension.
4.
To add an address to the Caller ID Based Services table, click Save.
5.
Click on the newly created Address in the Caller ID Based Services table to open the Caller ID Based Services for Address page.
6.
From the left frame, choose a Caller ID Based Services. From the right frame, enable, configure and adjust the corresponding service. Do this for each
7.
service. Remember to Save the configurations each time moving between the Caller ID Based Services configuration pages.
8.
Select the checkbox of the corresponding address that has to be edited in the Caller ID Based Services table. The Caller ID Based Services - Edit
To Edit Caller ID Based Services
Entry page will appear in the browser window.
1.
Change the Description of the address, if needed.
Change the Call Type and the Address defined in the corresponding fields.
2.
Change the Presence State of the extension, if needed.
3.
Save changes.
4.
If the reconfiguration of Caller ID Based Services is needed, click on the corresponding Address in the Caller ID Based Services table to open the
5.
Caller ID Based Services for Address page.
6.
From the left frame, choose a Caller ID Based Services. From the right frame, change the corresponding service settings, if required.
Save the configurations each time moving between the Caller ID Based Services configuration pages.
7.

Hiding Caller Information

The Hiding Caller Information service is used to hide QX IP PBX user information depending on the called destinations. When this service is activated,
Unknown or Anonymous (or similar text, depending on the type of the phone) will be displayed on the called phone when the current user of QX IP PBX
makes outgoing calls to the selected destination.
Using the "Block Last Caller" operation from the handset for the caller with the hidden caller ID (for example, anonymous@anonymous or
similar) may block all unknown callers.
Attention:
The Enable Service checkbox selection hides the current extension's information when calling to the corresponding Address listed in the Caller ID Based
Services table.
Even if the Hiding Caller Information service is
enabled, it shall work only for internal PBX calls and SIP calls. If you
Please Note:
call through FXO/ISDN port to a PSTN number, the called party will
still see your caller ID. To hide your caller ID for PSTN destinations,
contact your PSTN operator.
QX50/QX200/QX2000; (SW Version 6.0.x)
QX50/QX200/QX2000 Manual III: Extension User's Guide
Fig.III- 22: Hiding Caller Information page
Remember to
33
