Distance measurement

HINTS
LOGIQ V2/LOGIQ V1
Direction 5610736-100 Rev. 9
To make a distance measurement:
1. Press Measure key to enter into measure mode, if
necessary.
2. To position the active caliper at the start point, move the
Trackball.
3. To fix the start point, press Set.
The system fixes the first caliper and displays a second
active caliper.
4. To position the second active caliper at the end point, move
the Trackball.
A dotted line connects the measurement points, if preset
accordingly.
5. To complete the measurement, press Set.
The system displays the distance value in the Results
Window.
• Before you complete a measurement:
• To toggle between active calipers, adjust Cursor
Select.
• To erase the second caliper and the current data
measured and start the measurement again, press
Clear once.
• After you complete the measurement:
• To rotate through and activate previously fixed calipers,
adjust Cursor Select.
• To erase all data that has been measured to this point,
but not data entered onto worksheets, press Clear.
–
