GE LOGIQ V2 User Manual page 275

Label/Icon
Type/Class Label
IP Code (IPX8)
IPX8: FSU-1000, MKF 2-MED
GP26
LOGIQ V2/LOGIQ V1
Direction 5610736-100 Rev. 9
Table 4-6: Label Icons (Continued)
Purpose/Meaning
AC adapter for LOGIQ V2/LOGIQ
V1
No-Load power consumption
Average Active Efficiency
Test
Rechargeable Smart Battery
Pack
Only for LOGIQ V2/LOGIQ V1
system
Output
Used to indicate the degree of
safety or protection.
Indicates the degree of protection
provided by the enclosure per
IEC60 529.
Authorized European
Representative address.
United States only
Prescription Requirement label.
CAUTION: United States law
restricts this device to sale or use
by, or on the order of a physician.
Type BF Applied Part (man in the
box) symbol is in accordance
with IEC 60878-02-03.
General Warning.
–
User Guide
Device Labels
Location
AC adapter
AC adapter
AC adapter
Battery
Battery
Battery
AC adapter
Bottom of footswitch
Bottom panel
Bottom panel
Beside the probe connector
Various
