STANDARD ACCUFLOW™ DIAGRAMS
The AccuFlow Vortex one and two valve systems may be operated using standard Raven SCS control cabling.
Refer to the figure below for additional components used with the AccuFlow HP+ systems.
NOTE:
Contact a local Raven dealer for additional information or assistance with cabling or Raven AccuFlow
system components.
System Diagram and Replacement Parts: Standard AccuFlow™ Diagrams
S YSTEM DIAGRAM AND
C H A P T E R 8
REPLACEMENT PARTS
79
