AccuBoom™ Installation Manual
Miller Condor Series (CAN Product Control)

Advertisement

loading
Need help?

Need help?

Do you have a question about the AccuBoom Miller Condor Series and is the answer not in the manual?

Questions and answers

Related Manuals for Raven AccuBoom Miller Condor Series

Summary of Contents for Raven AccuBoom Miller Condor Series

  • Page 1 AccuBoom™ Installation Manual Miller Condor Series (CAN Product Control)
  • Page 2 GPS satellites, the OmniSTAR correction service or the WAAS correction service. Raven Industries accepts no responsibility for the use of the signal for other than the stated purpose. Raven Industries shall not be responsible or liable for incidental or consequential damages or a loss of anticipated benefits or profits, work stoppage or loss or impairment of data arising out of the use, or inability to use, the SmarTrax or any of its components.

  • Page 3: Basic Kit

    H A P T E R NTRODUCTION HAPTER Congratulations on your purchase of the Raven AccuBoom system! This system is designed to provide worry free turn-on and turn-off of your booms with respect to the as-applied coverage map. The following instructions are designed to assist you in the proper installation of the AccuBoom system.
  • Page 4 Miller Condor Series (CAN Product Control) AccuBoom Installation Manual Notes:...

  • Page 5: Installation

    Manual #016-1001-053 H A P T E R NSTALLATION HAPTER Use the following procedure to properly install the CAN AccuBoom system. Mounting the 1. Locate the center rack cross-member on the right rear corner of chassis. CAN Node 2. Attach the CAN node mounting bracket to the cross-member using the supplied U- bolts and hardware.

  • Page 6: Installing The Cable

    3. Tee in AccuBoom harness between the bulkhead and the previously disconnected harness. (See Figure 3) Figure 3: Tee in AccuBoom Harness 4. Connect the CAN Tee cable to the AccuBoom harness and connect to the Raven CAN Bus. Attach the terminator to the CAN tee Cable.

  • Page 7: Connecting The Power

    Manual #016-1001-053 Connecting the 1. Locate the battery box near the access ladder. (See Figure 4) Power Figure 4: Battery Box 2. Route the AccuBoom harness power lead to the battery box and connect directly to the battery. (See Figure 5) Figure 5: Connect Power Lead to the Battery.
  • Page 8 Miller Condor Series (CAN Product Control) AccuBoom Installation Manual...
  • Page 9 Manual #016-1001-053 H A P T E R IAGNOSTICS HAPTER The CAN AccuBoom node (P/N 063-0172-316) has additional features to allow the user to diagnose the AccuBoom system. The CAN AccuBoom node has a plastic window in the case that allows the user to view green diagnostic lights.
  • Page 11 How Can I Get Service? Bring the defective part and proof of purchase to your Raven Dealer. If your Dealer agrees with the warranty claim, the Dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
  • Page 12 P.O. Box 5107 Fax: 605-331-0426 Sioux Falls, SD 57117-5107 www.ravenprecision.com atdinfo@ravenind.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws.
