FIGURE 1. System Bleed and Emergency Shut-off (Top View)
Wind Direction for System
Bleed or Emergency Shut-off
5,6
System Bleed and Emergency Shut-off Components
TABLE 1.
Component #
1 Nurse Tank Main Shut-off and Bleed Valves (At Bulkhead or Withdrawal Valve)
2 Supply Hose Bleed Valves and Breakaway Couplers
3 Accuflow System Emergency Shut-off Valve and Rope to Tractor Cab
4 Accuflow System Primary Bleed Valve
5 Accuflow System Secondary Bleed Valve
6 Accuflow System Pressure and Temperature Gauges
7 Vapor Rows
Service and Maintenance:
4
3
1
Description
SERVICE AND MAINTENANCE
2
7
