Raven AccuFlow Vortex Installation And Operation Manual page 61

(SI Units) Given a target application rate of 68 kg(N)/ha at an average of 10 km/hr and a calculated implement
width of 1220 centimeters, the required capacity is:
The maximum capacity of the 80 GPM AccuFlow HP+ system is 336 lbs(N)/min [152 kg(N)/min].
SYSTEM CAPACITY CHART
NOTE: This figure assumes all recommended plumbing practices have been followed. Failure to follow to
those practices will limit the system capacity to lower values.
The following figure illustrates the capacity of the AccuFlow system in various configurations. Refer to this chart as
part of the calculation for required capacity and when troubleshooting the AccuFlow system.
FIGURE 5. System Capacity Chart
400
350
300
250
200
150
100
50
0
100 200
AccuFlow™ HP+ Calibration and Operation: Programming HP+ Rate Control - Viper Pro
150 x 5.5 x 480 = 606 lbs(N)/min
5940..........................
68 x 10 x 1220 = 13.8 kg(N)/min
60,000........................
80 GPM HP+ System Capacity
14 MPH Max
12 MPH Max
10 MPH Max
8 MPH Max
300 400 500
Implement Width (IN)
ACCUFLOW™ HP+ CALIBRATION AND OPERATION
600 700 800 900 1000 1100
(EQ 2)
(EQ 3)
1200
57
