Raven AccuBoom Installation Manual
Spracoupe 7460/ 7660
Hide thumbs
Also See for AccuBoom:
- Installation manual (26 pages) ,
- Calibration & operation manual (24 pages) ,
- Parallel installation manual (16 pages)
Subscribe to Our Youtube Channel
Related Manuals for Raven AccuBoom
Summary of Contents for Raven AccuBoom
- Page 1 SpraCoupe 7460/7660 AccuBoom™ Installation Manual P/N 016-1001-077 Rev C 04/16 E17443 Copyright 2011, 2016...
- Page 2 GPS, GNSS, SBAS, etc.). Therefore, Raven Industries cannot guarantee the accuracy, integrity, continuity, or availability of these services and cannot guarantee the ability to use Raven systems, or products used as components of systems, which rely upon the reception of these signals or availability of these services.
-
Page 3: Table Of Contents
AccuBoom Kit Contents ......................4 Chapter 3 AccuBoom Installation............7 Install the AccuBoom Node ....................... 7 Install the AccuBoom Harness Cable ..................8 Install the Power Connection ....................8 Connect the Harness to the Machine .................. 9 Chapter 4 Section Mapping Setup ............11 Envizio Pro .......................... - Page 4 Table of Contents SpraCoupe 7460/7660 AccuBoom Installation Manual...
-
Page 5: Important Safety Information
Raven dealer for support. • Follow all safety labels affixed to the AccuBoom system components. Be sure to keep safety labels in good condition and replace any missing or damaged labels. To obtain replacements for missing or damaged safety labels, contact your local Raven dealer. - Page 6 Chapter 1 SpraCoupe 7460/7660 AccuBoom Installation Manual...
-
Page 7: Chapter 2 Introduction
C h a p t e r 2 Introduction Congratulations on your purchase of the Raven AccuBoom system! This system is designed to provide accurate and cost-efficient application control by avoiding no-spray zones and eliminating wasteful overlaps. This manual applies to the following machines. For future reference, write your serial number in the space below. -
Page 8: Tools Needed
The instructions in this manual assume that you are standing behind the machine, looking toward the cab. AccuBoom Kit Contents This section contains a list of the components that are included in the AccuBoom kit. Before beginning the AccuBoom installation, compare the items in the AccuBoom kit with the components on this list. If you have questions about the kit, contact your local Raven dealer. - Page 9 Introduction AccuBoom Installation Kit (P/N 117-1004-077) TABLE 1. Picture Item Description Part Number Qty. Nut - 5/16”-18 Nylon Lock 312-4000-059 Washer - 5/16” Flat 313-2300-011 Manual No. 016-1001-077...
- Page 10 Chapter 2 SpraCoupe 7460/7660 AccuBoom Installation Manual...
-
Page 11: Accuboom Installation
C h a p t e r 3 Installation The instructions in this manual are designed to assist in the installation of the AccuBoom system on the 7460/ 7660 SpraCoupe sprayers. Refer to the Installation & Operation Manual for the specific field computer being used for instructions on setting up the software and using the AccuBoom system. -
Page 12: Install The Accuboom Harness Cable
Locate the CAN terminator on the CAN/Power extension harness or the previously installed AutoBoom harness cable (if applicable). Remove the CAN terminator and connect it to the connector labeled “CAN Bus” on the AccuBoom harness cable (P/N 115-1001-040). Connect the AccuBoom harness to the connector from which the CAN terminator was previously removed. -
Page 13: Connect The Harness To The Machine
Disconnect the black connector from the machine’s boom control node. Connect the black node connector to the receiving end on the AccuBoom harness cable (P/N 115-1001- 040). Connect the node connector on the AccuBoom harness cable to the open port of the machine’s boom control node. Note: The 3-pin Deutsch connectors on the AccuBoom harness cable should remain connected together. - Page 14 Chapter 3 SpraCoupe 7460/7660 AccuBoom Installation Manual...
-
Page 15: Section Mapping Setup
C h a p t e r 4 Setup This section contains section mapping setting that are used to program the AccuBoom controller. Refer to the Installation & Operation Manual and the appropriate section in this chapter for the specific field computer being used for programming instructions and section mapping settings. -
Page 16: Viper Pro
5 Section 8 Section Boom Wired As Display As Boom Wired As Display As Important: The AccuBoom node “Combo” setting must be selected under the Miscellaneous Settings tab for the AccuBoom system to function properly. SpraCoupe 7460/7660 AccuBoom Installation Manual... -
Page 17: Troubleshooting
AccuBoom system. Note: If the LEDs are not displayed as outlined in the figure below, check the CAN connections and the control cable connections on the node. If the issue persists, contact your local Raven dealer for additional technical support. Note: All boom switches must remain in the On position while AccuBoom control is in operation. - Page 18 Chapter 5 SpraCoupe 7460/7660 AccuBoom Installation Manual...
- Page 19 Index AccuBoom Installation 7 Installing the AccuBoom Harness 8 Installing the AccuBoom Harness Cable Connecting the Harness to the Machine 9 Installing the AccuBoom Node 7 Installing the Harness Cable Installing the Power Connection 8 Introduction AccuBoom Kit Contents 4...
- Page 20 Index SpraCoupe 7460/7660 AccuBoom Installation Manual...
- Page 21 How Can I Get Service? Bring the defective part and proof of purchase to your Raven dealer. If your dealer agrees with the warranty claim, the dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
