CHAPTER 3
ACCUFLOW™ VAPOR AND APPLICATOR PLUMBING INSTALLATION
The following will step through the final system connections for the AccuFlow Vortex cooler and NH
Generic Control valves used with liquid systems are not acceptable for NH
for NH are required. Special NH
3
insecticides, and liquid fertilizer.
1. Connect the hose barb fittings to the vapor ports on the cooler as shown below.
FIGURE 29. AccuFlow Cooler Vapor Tube Installation
Vortex Cooler
Applicator Knife
Orifice (Optional,
Not Supplied)
2. Connect vapor tube hoses to vapor ports, tee and steel vapor tubes.
3. Weld vapor tubes provided with the kit to the back of liquid tubes. Vapor tubes should be spaced out evenly
across the tool bar. Avoid connecting vapor tubes on wheel tracks and adjacent rows if possible.
4. Route 3/4" tubing from the 3/4" cooler vapor ports to the vapor tube tee as shown in figure. Cut tube lengths
in equal lengths and allow enough hose to avoid kinking at any folding points. Connect one end of the vapor
38
Anhydrous ammonia in vapor form can cause
serious injury or death. Pipe joints must be
properly sealed with PTFE pipe thread sealant, or
an equivalent thread sealant, to prevent leaks.
valves can be used for other applications; i.e. herbicides,
3
1" Vapor Port (Each Side)
Vapor Rows with
Steel Vapor Tubes
Anhydrous ammonia in vapor form can cause
serious injury or death. Pipe joints must be
properly sealed with PTFE pipe thread sealant, or
an equivalent thread sealant, to prevent leaks.
AccuFlow™ Vortex and AccuFlow™ HP+ Installation and Operation Manual
DANGER
. Valves specially designed
3
DANGER
plumbing.
3
3/4" Vapor Hose
(Not Supplied)
Toolbar
