The following sections are included to illustrate the proper procedure for mounting and plumbing the AccuFlow
system.
This section assumes that the Raven control console has already been installed and all installation and safety
procedures have been completed or understood.
NOTE: In addition to the Raven control console and associated cabling, a speed sensor and flow cabling
must also be installed with the Raven AccuFlow system. Refer to Testing the Speed Sensor Extension
Cable section on page 77 for examples of AccuFlow systems and cable connections. Contact a local
Raven dealer for more information and assistance.
When installing hoses, cables, and wires always take care that they cannot be pinched, cut, or otherwise damaged
during normal operation.
FIGURE 1. Typical Vortex System Single and Dual Valve
Control or Fast Valve
Pressure
Bleed Circuit
Gauge
Pressure Hose
Connection
Manifold
Liquid
Applicator
On/Off Valve
Tube
(Not Used with
Fast Valve)
Primary Bleed
Valve
AccuFlow™ Vortex and AccuFlow™ HP+ Installation:
A CCUFLOW™ VORTEX AND
C H A P T E R 3
ACCUFLOW™ HP+
INSTALLATION
Anhydrous ammonia can cause severe burning,
blindness, or death. Refer to Discharging the
AccuFlow™ System section on page 5 or page 61
and follow the procedure for bleeding the
AccuFlow system before beginning maintenance.
Temperature Gauge
Vortex Cooler
Flowmeter
Secondary Bleed
Valve
Bleed Line
DANGER
Bleed Circuit Vapor
Hose Connection
Emergency Shut-Off
Valve
Strainer/
Magnet
Assemblies
Vapor Hose
Steel Vapor Tubes
Hose to
Breakaway
Check Valve
Assemblies
