CHAPTER 6
FIGURE 2. System Bleed and Emergency Shut-off (Side View)
Pressure
Bleed Circuit
Gauge
Pressure Hose
Connection
Secondary Bleed
Valve
Primary Bleed
Valve
64
Temperature Gauge
Vortex Cooler
Bleed Line
AccuFlow™ Vortex and AccuFlow™ HP+ Installation and Operation Manual
Bleed Circuit Vapor
Hose Connection
Emergency Shut-Off
Valve
Hose to
Breakaway
Toolbar
Vapor Hose
