Chapter 2
During the installation process, follow good safety practices. Be sure to carefully read the instructions in this
manual as you complete the installation process.

Recommendations

Raven Industries recommends the following best practices when installing or operating the SmarTrax system
for the first time, at the start of the season, or when moving the SmarTrax system to another machine:
•
Install the GPS antenna in the recommended location. Refer to the following table for the machine-specific
antenna mounting location.
Machine Preset
Versatile 260-310 2013
•
Ensure the machine's hydraulic filters have been recently changed and there are no issues with the
machine's hydraulic system (e.g., pump issues, faulty hydraulic motors, fine metal deposits in the hydraulic
hoses, etc.).
•
Ensure the machine's hydraulic system is using fresh oil and debris is flushed from the hydraulic hoses,
valves, and filters.
Raven Industries recommends the following best practices when installing the SmarTrax system:
•
Use part numbers to identify the parts.
•
Do not remove the plastic wrap from a part until it is necessary for installation.
•
Do not remove plastic caps from a part until it is necessary for installation.

Point of Reference

The instructions in this manual assume that you are standing behind the machine, looking toward the cab.

Updates

Software and manual updates are available on the Raven Applied Technology website:
4 Buhler Versatile Row Crop R2 Series 250-310 SmarTrax™ Installation Manual
Antenna X Position Antenna Y Position
(left to right)
Centered
http://www.ravenhelp.com
Antenna Z Position
(ground to bottom of
(fore/aft offset)
5 ft./1.524 m 11 ft. 2 in./3.399 m
antenna)
