Screw fittings

The following tables show the screw fittings available from SEW‑EURODRIVE:
11.8.1 Cable glands / screw plugs / pressure compensation
Type of screw
fitting
Screw plugs
external
hexagon (made
of stainless
steel)
Pressure com-
pensation
screw fittings
(made of stain-
less steel)
EMC cable
gland (brass,
nickel-plated)
EMC cable
gland (made of
stainless steel)
1) The specified torques must be adhered to with a tolerance of +/- 10%.
The cable retention in the cable gland must withstand the following removal force of
the cable from the cable gland:
•
•
Figure
Cable with outer diameter > 10 mm: ≥ 160 N
Cable with outer diameter < 10 mm: = 100 N
Technical data and dimension sheets
Con- Size Tighten-
tent ing
torque
10 pcs M16 × 6.8 Nm
1.5
10 pcs M25 × 6.8 Nm
1.5
1 piece M16 × 4 Nm
1.5
10 pcs M16 × 4 Nm
1.5
10 pcs M25 × 7 Nm
1.5
10 pcs M16 × 4 Nm
1.5
10 pcs M25 × 7 Nm
1.5
Operating Instructions – MOVIMOT
Screw fittings
Outer Part num-
cable ber
1)
diame-
ter
– 18247342
– 18247350
– 28214617
5 to 18204783
9 mm
11 to 18204805
16 mm
5 to 18216366
9 mm
11 to 18216382
16 mm
®
flexible
