Operation
7
Binary control
7.2.3 Configuration 2: Enable, fixed setpoints
Behavior of the drive unit
The drive unit stops with deceleration setpoint t1.
FCB 01 Output stage inhibit is activated afterwards.
The drive unit is running with the fixed speed setpoint 1.
The direction of rotation is specified by the sign of the
fixed setpoint.
The acceleration setpoint t1 is active.
The drive unit is running with the fixed speed setpoint 2.
The direction of rotation is specified by the sign of the
fixed setpoint.
The acceleration setpoint t1 is active.
The drive unit is running with the fixed speed setpoint 3.
The direction of rotation is specified by the sign of the
fixed setpoint.
The acceleration setpoint t1 is active.
The drive unit is running in positive direction of rotation
(clockwise rotation) with the analog speed setpoint f1.
The acceleration setpoint t1 is active.
The drive unit is in fault state.
The fault state has been reset.
1) If potentiometer t1 is deactivated using the parameter settings, the acceleration setpoint 1/ deceleration setpoint 1 of the fixed set-
point processing will be activated.
2) If DIP switch S2/2 (Analog setpoint selection) is set to "ON", the speed setpoint of analog input AI1 is used instead of speed setpoint
f1.
0 = No voltage
172
Operating Instructions – MOVIMOT
Fixed setpoint processing mode:
1)
1)
1)
1)
1 = 24 V
®
flexible
Mechanical setting elements
(cannot be changed)
Digital input
DI01 DI02
Enable Fixed
setpoint
0
2
1)
0 x
1 1
1 0
1 1
1 0
2)
x x
0 0
x = Any
"DRIVE"
LED
DI03 DI04
Fixed Reset
setpoint
1
2
x x Lights up
yellow
0 x Illuminated
in green
1 x Illuminated
in green
1 x Illuminated
in green
0 x Illuminated
in green
x x Lights up
or flashes
red
0 1 Lights up
yellow
