11.5.5 Technical data of BW150-006-T and BW100-009-T
Power diagrams
The following figure shows the rating diagrams of the braking resistors BW150-006-T
and BW100-009-T:
[1]
[2]
ED Cyclic duration factor of the braking resistor, based on a cycle time of 120 s.
Dimension drawing of BW150‑006-T
The following figure shows the dimensions of the external braking resistor
BW150‑006-T:
100
10
1
0.1
1
Power in KW
Cyclic duration factor cdf in %
Technical data and dimension sheets
BW100-009-T
BW150-006-T
10
[2]
166
110
ø7x11
<285
Operating Instructions – MOVIMOT
11
Braking resistors
100
25298798219
65
25298808587
