Startup
6

Configuring the digital inputs/outputs

6.10 Configuring the digital inputs/outputs
Easy mode (deliv-
ery state)
Expert mode
162
Operating Instructions – MOVIMOT
In Easy mode, the following configuration of the digital inputs is active:
Digital inputs
Function
(Configuration of the digital inputs)
• DI01
• DI02
• DI03
• DI04
Digital outputs
Function
DOR (relay output)
In Expert mode, you can assign other functions to the digital inputs and to the relay
output, either individually or using predefined configurations of the digital inputs.
®
flexible
Setting
(CW/CCW/setpoint changeover)
Fixed setpoints, positive rotation direc-
tion
Fixed setpoints, negative rotation direc-
tion
Potentiometer f2
Fault reset
Setting
Ready for operation
