igus chainflex
The following table shows the conductor assignment of cables with the following part
numbers:
Part numbers
28117816, 28111044
Assembly
Open cable end
Core Identi- Assembly
color/core fication
cross sec-
tion
1)
Not pre-
–
fabricated
Black Not pre-
1
2
0.75 mm fabricated
1)
Not pre-
–
fabricated
Black Not pre-
2
2
0.75 mm fabricated
Black Not pre-
3
2
0.75 mm fabricated
1) Do not connect these cores in the plug connector.
Assignment of the optional plug connectors
Description
DC 24 V auxiliary output
F_STO_P2 connection
0V24 reference potential
for DC 24 V auxiliary output
F_STO_P1 connection
F_STO_M connection
Operating Instructions – MOVIMOT
Electrical installation
Prefabricated plug
connectors
1
2
4
3
5
Signal Contact
24V_OUT 1
F_STO_P2 2
0V24_OUT 3
F_STO_P1 4
F_STO_M 5
®
flexible
5
103
