10.6

Motor/inverter assignments

The following motor/inverter assignments are valid for MOVIMOT
10.6.1 Technical data DR.. motors
Key
P
N
M
N
n
N
I
N
cosφ
IE
η
50%
η
75%
η
100%
I /I
A
M
A
M
H
M
K
m
J
Mot
BE..
Z
0
Z
0
M
B
m
B
J
MOT_BE
Rated power
Rated torque
Rated speed
Rated current
Power factor
Short for "International Efficiency" (international efficiency class IE1 –
IE4)
Efficiency at 50% of the rated power
Efficiency at 75% of the rated power
Efficiency at 100% of the rated power
Starting current ratio
N
/M Starting torque ratio
N
/M Ramp-up torque ratio
N
/M Breakdown torque ratio
N
Mass of the motor
Mass moment of inertia of the motor
Brake used
BG Switching frequency for operation with BG brake control
BGE Switching frequency for operation with BGE brake control
Braking torque
Mass of the brakemotor
Mass moment of inertia of the brakemotor
Project planning
Motor/inverter assignments
®
flexible.
