Welch Allyn 5002 Service Manual page 97

5122 Repair Parts
Table 23 5122 Top Level Assembly
Unique Welch Allyn
Identifier Part Number
1
2
10
3 48112
4 412464
5 130212
6 726602
7 030169W
8 40564
9 726496
Qty Welch Allyn Part Number Description
1 SEE SLIDER BASE EXPLODED VIEW
SEE 5122 MAST EXPLODED VIEW
6 SCW, 1/4-20 X 1/2" BHCS, SS, PASSIVATED
1 SEE READOUT PANEL EXPLODED VIEW
10 10-32X1/4 SCREW - BHMS SOC
1 OVERLAY GRAPHIC MAST WOPRINT SCALE-T
1 BACK PANEL SLIDER MAST
1 HANDLE RECESSED PLASTIC
1 BRACKET 5122 SLIDER-MAST COVER SCALE-T
Table 29
Table 25
Table 24
