Welch Allyn Pediatric/Infant Scale
Directions for use
Model 4802D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4802D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Welch Allyn 4802D

Summary of Contents for Welch Allyn 4802D

  • Page 1 Welch Allyn Pediatric/Infant Scale Directions for use Model 4802D...
  • Page 2 © 2016 Welch Allyn. All rights are reserved. To support the intended use of the product described in this publication, the purchaser of the product is permitted to copy this publication, for internal distribution only, from the media provided by Welch Allyn. No other use, reproduction, or distribution of this publication, or any part of it, is permitted without written permission from Welch Allyn.

  • Page 3: Table Of Contents

    Contents Introduction ..................... 1 Intended use ......................1 Indications for use ....................1 Symbols ....................... 1 About warnings and cautions ................2 Controls and indicators ..................3 Assembly and setup ................5 Assembly instructions ..................5 Custom setup ...................... 5 Scale operation ..................
  • Page 4 Contents Welch Allyn Pediatric/Infant Scale...

  • Page 5: Introduction

    Introduction Intended use The Welch Allyn Pediatric/Infant Scale is intended to be used by clinicians for weighing patients from 0.35 oz to 44 lbs (10 g to 20 kg) and measuring patients up to 32 inches (81 cm), depending on the size of the scale cradle.

  • Page 6: About Warnings And Cautions

    Caution statements can appear on the Welch Allyn Pediatric/Infant Scale, the packaging, the shipping container, or in this Directions for use. The Welch Allyn Pediatric/Infant Scale is safe for patients and clinicians when used in accordance with the instructions and caution statements presented in this Directions for use.

  • Page 7: Controls And Indicators

    Directions for use Introduction 3 General warnings and cautions WARNING Patient injury risk. Never leave the infant unattended on the scale. Only remove your hands from the infant for a brief amount of time to allow for an accurate weight measurement. WARNING Patient injury risk.
  • Page 8 4 Introduction Welch Allyn Pediatric/Infant Scale Digital display Stainless steel cabinet N/A Line cord, power supply, and plug (on rear panel) Front panel buttons Button Function ON / (OFF) / Briefly press this button to turn the scale on. ZERO Press and hold this button to turn the scale off.

  • Page 9: Assembly And Setup

    Assembly and setup The scale is fully assembled at the factory and tested. In some instances, the scales are shipped assembled. However, due to size and shipping restrictions, most scales are partially disassembled. If assembly is required, it can be done with common hand tools. When special tools are required, they are supplied with the scale.
  • Page 10 OUNCES* This option allows the weight to display in ounces. bEEPEr* This option determines the audible signal that occurs when a front panel button is pressed. rS-232 Detailed instructions for this feature are available from Welch Allyn. Go to http:// www.welchallyn.com/en/other/contact-us.html to find your local representative.
  • Page 11 Directions for use Assembly and setup 7 PrtOPT* RECALL PRIOR WEIGHT Press to choose between the following options: PnlPrt DATA SEND : The current weight is sent to a computer when is pressed on the control panel. AutPrt : The current weight is automatically sent to a computer when a weight reading occurs. bAud* 1200 2400...
  • Page 12 8 Assembly and setup Welch Allyn Pediatric/Infant Scale...

  • Page 13: Scale Operation

    Scale operation Power options The scale can be used with battery power or with AC power. Battery power CAUTION Use only size D disposable alkaline batteries. The use of any other battery will void the warranty. Press ON / (OFF) / ZERO to turn on the scale. The scale automatically turns off after 90 seconds of non-use when operating on battery power.

  • Page 14: One-Gram Weighing Option

    10 Scale operation Welch Allyn Pediatric/Infant Scale Continuous There is a problem with the scale. See the troubleshooting section. long beep One-gram weighing option This purchasable option allows the scale to display weights below 1 kilogram in 1-gram increments with 1-gram resolution. It is automatically enabled whenever the weight on the cradle is less than 1 kilogram.

  • Page 15: Storage, Cleaning, And Maintenance

    Storage, cleaning, and maintenance Storage The scale should be stored on a stable surface. If not, the scale should be stored in a convenient storage facility or closet. At no time should the scale be lifted by grasping the cradle. During storage or shipping, disconnect the cradle from the scale to prevent damage to the scale’s electronic transducers.

  • Page 16: Maintenance

    12 Storage, cleaning, and maintenance Welch Allyn Pediatric/Infant Scale 5. Re-install the cradle by gently pressing down. Maintenance Routinely perform the following preventive maintenance to keep your scale in working order. 1. Check the calibration annually or as required. 2. Inspect the cradle for cracks or loose mounting hardware. Replace or repair as necessary.
  • Page 17 Directions for use Storage, cleaning, and maintenance 13 Issue Possible cause Suggested action The scale buttons are not The buttons are damaged Check for visible signs of responding damage. Contact your service department. E-FAIL The scale's EEPROM memory has failed Contact your service department.
  • Page 18 14 Storage, cleaning, and maintenance Welch Allyn Pediatric/Infant Scale...

  • Page 19: Appendices

    Appendices Specifications Item Specification Scale 4802D Resolution (factory default) 0.2 oz/5 g 1-gram option: 1 g below 1 kg Weighing range 0.35 oz to 44 lbs (10 g to 20 kg) Readout Large, bright, light-emitting diode display. Selectable weight display in grams, kilograms, or pounds and ounces.

  • Page 20: Product Configurations

    Mobile weighing cart with tissue dispenser Warranty Welch Allyn will warranty the weight scale to be free of defects in material and workmanship and to perform in accordance with manufacturer specifications for the period of one year from the date of retail purchase.
  • Page 21 Directions for use Appendices 17 Should this device require maintenance (or replacement at our option) under warranty, contact your local Welch Allyn representative: http://www.welchallyn.com/en/other/ contact-us.html...
