Welch Allyn 5002 Service Manual page 22

0.1 pounds / 0.1 kilograms
0.2 pounds / 0.1 kilograms
0.5 pounds / 0.2 kilograms
1 pound / 0.5 kilograms
UnitS allows the user to configure the units the scale will be able to use in typical display mode.
Locking this to a specific unit will also restrict what units can be printed.
Note: If all units are set to Off, the scale defaults to KILOS.
UI Display Light ON
KILOGRAMS
KILOGRAMS and
POUNDS
POUNDS
bEEPEr allows the user to configure the external buzzer. The default is On.
rEcALL allows the user to configure whether the scale can be powered on in recall mode. If set
to OFF, then Recall key will not operate.
USb allows the user to send weight data to the computer. ON is to enable usb data transfer
option, OFF is to disable usb data transfer option.
PrntEr allows the user to send weight data to the built-in-printer. ON is to enable printer option,
OFF is to disable printer option.
PrtUnt allows the user to configure which unit will be shown on the USB data transfer. If both
units are selected then the scale will use the units displayed at time of printing. Cycles through
unit options (lb only, kg only, lb-kg). This option determines whether pounds or kilograms are
displayed on a printout. If the pounds and kilograms indicators are illuminated on the control
panel, the printed output is determined by whichever unit is selected on the control panel. If the
kilogram indicator is illuminated, it will only print in kilograms, regardless of the unit that is
selected on the control panel. If the pounds indicator is illuminated, it will only print in pounds,
regardless of the unit that is selected on the control panel. Same as Ounces, Pounds-Ounces
unit.
PrtOPt allows the user to configure sending weight manually using the SEND DATA key or
automatically. PnlPrt is the manual setting and AutPrt is the automatic setting
For the scales that do not support print or send data, the corresponding menus in Setup Mode
are disabled and the option do not show in Setup mode.
Menu will restart to FACtrY menu title when you have cycled through all the options.
Power off scale to exit Service Mode
This option displays the weight in kilograms (0.0). Default is On
This option displays the weight in pounds and kilograms. Default is On
This option displays the weight in pounds (0.0). Default is OFF
22
