Welch Allyn 5002 Service Manual page 131

Unique Welch Allyn
Identifier Part Number
1 726498
2 CS-206
3 726340
4 139040
5 60624
6 726253
7 726461
8 700000W
9 50529
10 726773
11 50502
12 50314
13 50614
14 52523
15 412601
16 106100-4
17 039325W
18 130212
19 727292
20 727014
21 726348
22 133086
23 900001W
24 726341
25 727578
26 727547
27 50542
28 48611
29 N/A
30 48113
31 106137-7
32 726349
33 727307
34 130060
35 039319W
36 039312W
37 029073W
38 531012
39 30378
Qty Welch Allyn Part Number Description
1 WELDMENT, BASE, 6702, SCALE-T
8 WASHER, FENDER .28" X 1.5"
8 WSHR,0.281"ID,1.5"OD,0.11"- 0.14THK
8 FOOT PLASTIC I 3/4" X 3/8"
8 SCREW 1/4-20 X 1" FHSS
4 BRACKET, 6702-SP STABILIZER SCALE-T
12 NUT, 1/4-20 SER FLNG LOCK, SS
4 L-ANGLE SUPPORT ASSY, 6702SP
4 1/4-20 X 3/4 BUTT HD SOCK SCR
4 SCW 5/16-18 1/2" ROUNDED CAP, VIBRATITE
2 WHEEL 4"
2 BUSHING, WHEEL 5/16" X 1"
2 SCW, 5-16-24 X 1 3/4" HEX CS GRD 8, NICK
2 NUT, 5/16-24 HEX NKL
1 HARNESS, INTERIOR, BASE, SHORT, SCALE-T
4 SCREW, 4-40 x .380 PHP
1 CABLE GUARD
38 10-32 X 1/4 SCREW - BHMS SOC
2 LOAD CELL SPACER 4HOLE SCALE-T
2 LOAD CELL, DEBBW-1000LB, 3S, SCALE-T
4 WASHER,1/4" ID X 1"OD X 0.060"-0.090"TH
4 LOADMOUNT 3/8" X 1" WITH 3/8"
4 BRACKET, ISOLATION LIMITER
4 SHOULDER SCREW 1/2" OD X 1/4" L
8 1/4 SPLIT RING LOCKWASHER, SS
8 SCREW, 1/4-20 X 1.75 HHCS SS
6 CLIP, METAL CABLE 3/16"
14 SCW, 6-32 X 1/4" PHMS SEMS, NICKEL
N/A Not used. Replaced with 50542.
4 SCW, 6-32 X 3/8" PHIL PAN HD NICKEL
4 NUT 6-32 LOCKING HEX
1 PCBA, MEASUREMENT BOARD, SCALE-T
1 BRACKET, LOADCELL, 6702, SCALE-T
6 SCREW 10-32 X 1/2" FHS FOR DELRON
1 DECK, OVERSIZE 30" X 35"
2 PLATFORM RAMP 29" 6702
2 PLATFORM HINGE 29" 6702
2 SHUR-STEP MAT·12" X 11 3/4" (2 PCS)
10 10-24 X 1/2 FH SOC SCR
131
