6702/6702W/6702SP Loadcell Assembly
Table 18 6702/6702W/6702SP Loadcell Assembly
Unique
Welch Allyn
Identifier
Part Number
1
727014
2
726348
3
133086
4
900001W
5
726341
Qty Welch Allyn Part Number Description
1
LOAD CELL DEBB-1000LB 3S SCALE-T
2
WASHER,1/4"IDX1"ODX0.060"-0.090"TH
2
LOADMOUNT 3/8" X 1" WITH 3/8"
2
BRACKET, ISOLATION LIMITER
2
SHOULDER SCREW 1/2" OD X 1/4" L
80
