Base Wiring Harnesses
Table 32 5122 Base Wiring Harnesses
Unique
Welch Allyn
Identifier
Part Number
1
726899
2
138019
3
412602
4
727162
5
715822
6
113P464
7
727306
8
106137-7
Qty Welch Allyn Part Number Description
4
LOAD CELL, GPBS-150KG, 3S, SCALE-T
6
TAPE, ALUMINUM 3/4" X 60YD
1
HARNESS, LOW, D-PCA TO M-PCA, SCALE-T
1
ADHESIVE BACKED, LATCHING, WIRE CLIP
1
CABLE TIE HOLDER WITH ADHESIVE
1
CABLE TIE, 6 INCH
1
HARNESS, CONT, GND, SCALE-T
2
NUT 6-32 LOCKING HEX
104
