Welch Allyn 5002 Service Manual page 83

6702SP Wiring Harness
Table 21 6702W Wiring Harness
Unique Welch Allyn
Identifier Part Number
1 727014
2 412601
3 727162
4 715822
5 113P464
6 727306
7 50542
8 N/A
9 48113
10 106137-7
11 48611
Qty Welch Allyn Part Number Description
2 LOAD CELL, DEBBW-1000LB, 3S, SCALE-T
1 HARNESS, INTERIOR, BASE, SHORT, SCALE-T
2 ADHESIVE BACKED, LATCHING, WIRE CLIP
1 CABLE TIE HOLDER WITH ADHESIVE
1 CABLE TIE, 6 INCH
1 HARNESS, CONT, GND, SCALE-T
6 CLIP, METAL CABLE 3/16"
N/A Not used. Replaced with 50542.
4 SCW, 6-32 X 3/8" PHIL PAN HD NICKEL
4 NUT 6-32 LOCKING HEX
4 SCW, 6-32 X 1/4" PHMS SEMS, NICKEL
83
