Welch Allyn 5002 Service Manual page 45

5002, 5702, 6002, 6702, 6702W, 6702SP MAST Exploded Repair Parts view diagram
Mast Repair Parts
Table 1 Mast Repair Parts
Unique Welch Allyn
Identifier Part Number
1
15
16
2 412432
3 726494
4
5 130204
6 726612
726975
7 130237
8
9 130212
10
11 726746
12
14
Qty Welch Allyn Part Number Description
SEE MAST BODY ASSY EXPLODED VIEW Table 2
1 HARNESS POWER JACK DC 2.5MM SCALE-T
2 SCREW 1/32X3/8 THREAD FORM
SEE BATTERY BRACKET ASSY EXPLODED VIEW Table 6
4 SCW, 6-32 X 1/4" FHMS UNDERCUT, ZINC
1 PANEL, MAST, BATT ACCESS, SCALE-T
1 LABEL SCALE-T BATTERY DOOR
2 SCW 10-32X3/8 PHIL RND MS SS
SEE PRINTER ASSY EXPLODED VIEW Table 5
2 10-32 X 1/4 SCREW – GHMS SOC
SEE USB ASSY EXPLODED VIEW Table 4
2 SCREW, 6-32X7/16", HEX RHS, ZINC STEEL
SEE READOUT ASSY EXPLODED VIEW Table 3
45
