6002 Repair Parts
Unique
Welch Allyn
Identifier
Part Number
1
2
5
6
3
132074
4
130234
7
726551
6002 Top Level
Qty Welch Allyn Part Number Description
SEE 6002 EXPLODED REPAIR PARTS
SEE MAST BODY ASSY EXPLODED VIEW Table 2
2
WASHER 3/8 IDXI ODSS
2
BOLT 3/8-16X3 3/4HEX HEAD
1
POWER SUPPLY, EXT, 12VDC
Table 9
41
