Welch Allyn 5002 Service Manual page 76

6702W Base Assembly
Table 16 6702W Base Assembly
Unique Welch Allyn
Identifier Part Number
1 726498
2 CS-206
3 726340
4 139040
5 60624
6 50502
7 50314
8 50614
9 52523
10 412601
Qty Welch Allyn Part Number Description
1 WELDMENT, BASE, 6702, SCALE – T
6 WASHER, FENDER 0.28" X 1.5"
6 WSHR 0.281" ID, 1.5" OD, 0.11"- 0.14 THK
6 FOOT PLASTIC I 3/4" X 3/8"
6 SCREW 1/4-20 X 1" FHSS
2 WHEEL 4"
2 BUSHING, WHEEL 5/16" X 1"
2 SCW, 5-16-24 X 1 3/4" HEX CS GRD 8, NICK
2 NUT, 5/16-24 HEX NKL
1 HARNESS, INTERIOR, BASE, SHORT, SCALE-T
76
