Unique Welch Allyn
Identifier Part Number
1 726498
2 CS-206
3 726340
4 139040
5 60624
6 50502
7 50314
8 50614
9 52523
10 412601
11 106100-4
12 039325W
13 130212
14 727292
15 727014
16 726348
17 133086
18 900001W
19 726341
20 727578
21 727547
22 50542
23 48611
24 N/A
25 48113
26 106137-7
27 726349
28 727307
29 130060
30 039311W
31 039312W
32 029073W
33 531012
34 30378
35 139041
49 727201
50 039301W
51 039302W
Qty Welch Allyn Part Number Description
1 WELDMENT, BASE, 6702, SCALE-T
4 WASHER, FENDER .28" X 1.5"
4 WSHR,0.281"ID,1.5"OD,0.11"- 0.14THK
4 FOOT PLASTIC I 3/4" X 3/8"
4 SCREW 1/4-20 X 1" FHSS
2 WHEEL 4"
2 BUSHING, WHEEL 5/16" X 1"
2 SCW, 5-16-24 X 1 3/4" HEX CS GRD 8, NICK
2 NUT 5/16-24 HEX NKL
1 HARNESS INTERIOR BASE SHORT SCALE-T
4 SCREW 4-40 X .380 PAN PHILLIPS
1 CABLE GUARD
38 10-32 X 1/4 SCREW - BHMS SOC
2 LOAD CELL SPACER 4HOLE SCALE-T
2 LOAD CELL, DEBBW-1000LB, 3S, SCALE-T
4 WASHER,1/4" ID X 1"OD X 0.060"-0.090"TH
4 LOADMOUNT 3/8" X 1" WITH 3/8"
4 BRACKET, ISOLATION LIMITER
4 SHOULDER SCREW 1/2" OD X 1/4" L
8 1/4 SPLIT RING LOCKWASHER, SS
8 SCREW, 1/4-20 X 1.75 HHCS SS
6 CLIP, METAL CABLE 3/16"
14 SCW, 6-32 X 1/4" PHMS SEMS, NICKEL
N/A Not used. Replaced with 50542.
4 SCW, 6-32 X 3/8" PHIL PAN HD NICKEL
4 NUT 6-32 LOCKING HEX
1 PCBA, MEASUREMENT BOARD, SCALE-T
1 BRACKET, LOADCELL, 6702, SCALE-T
6 SCREW 10-32 X 1/2" FHS FOR DELRON
1 PLATFORM, 6702 28" X 31"
2 PLATFORM RAMP 29" 6702
2 PLATFORM HINGE 29" 6702
2 SHUR-STEP MAT·12" X 11 3/4" (2 PCS)
10 10-24 X 1/2 FH SOC SCR
2 WASHER FLAT NYLON 1 1/4" X 1/4"
1 MAST CASE, HIGH, WITH PRINTER, SCALE-T
1 HANDLE MAST GRAY
2 PIN ALIGNER MAST HANDLE
