Welch Allyn 5002 Service Manual page 119

Unique Welch Allyn
Identifier Part Number
1b 726497
2b 139040
3b 726749
4 50502
5 50314
6 50614
7 52523
8 412469
9 106100-4
10 039325W
11 130212
12 50542
13 726613
14 726614
15 726615
16 106137-4
17 133110
18 726349
19 48611
20 33004
21 130237
22 50509
23b 030352W
24 40408
26b 030208W
27 66164
49 727201
50 039301W
51 039302W
52 30374
53 25066
54 726603
55 412432
56 726494
57 726616
58 412431
59 24014
60 130204
61 749201
Qty Welch Allyn Part Number Description
1 BASE WELDMENT 6002/6502 SCALE-T
6 FOOT PLASTIC I 3/4" X 3/8"
6 SCW, 1/4-20 X 5/8", HEX, BUTTON HEAD, SS
2 WHEEL 4"
2 BUSHING, WHEEL 5/16" X 1"
2 SCW, 5-16-24 X 1 3/4" HEX CS GRD 8, NICK
2 NUT,5/16-24 HEX NKL
1 HARNESS INTERIOR BASE LONG SCALE-T
4 SCREW 4-40 X .380 PAN PHILLIPS
1 CABLE GUARD
7 10-32 X 1/4 SCREW - BHMS SOC
1 CLIP, METAL CABLE 3/16"
1 BOTTOM PAN 5002, SCALE-T
4 PLATE, OVERLOAD PROTECT, 500LB-DWB
4 LOAD CELL 500 LB DWB-SCALE-T
8 NUT,10-32 EXTLOCK
4 MOUNT METAL LOAD
1 PCBA MEASUREMENT BOARD-SCALE-T
10 SCW, 6-32 X 1/4" PHMS SEMS, NICKEL
6 WSH 1/4 STEEL SPLIT LOCK
6 SCW 10-32X3/8 PHIL RND MS SS
4 1/8 THICK EAR SPACER 3/4" X 3/4"
1 PLATE 6002 GPR TOP
4 BHSCS 10-32 X 3/8 18-8 STAINLESS STEEL
1 DECK PLATFORM BASE 5702
4 1/4-20 X 1/2 FLAT HD SOCK SCR
1 MAST CASE, HIGH, WITH PRINTER, SCALE-T
1 HANDLE MAST GRAY
2 PIN ALIGNER MAST HANDLE
2 WASHER, 0.318" ID X 0.738" OD X 0.062 TK
2 BOLT. 1/4-20 X 1" HEX HEAD, SS
1 HARNESS INTERIOR MAST COMMON SCALE-T
1 HARNESS POWER JACK DC 2.5MM SCALE-T
2 SCREW 1/32X3/8 THREAD FORM
1 BRACKET, MAST, BATT HLD, SCALE-T
1 HARNESS BATT HOLDER W/GRD SCALE-T
6 SCW 6-32X1/4 PHIL PAN STEEL NICKEL
4 SCW, 6-32 X 1/4" FHMS UNDERCUT, ZINC
6 "D" CELL BATTERY
119
