Welch Allyn 5002 Service Manual page 122

Unique Welch Allyn
Identifier Part Number
1b 726497
2b 139040
3b 726749
4 50502
5 50314
6 50614
7 52523
8 412469
9 106100-4
10 039325W
11 130212
12 50542
13 726613
14 726614
15 726615
16 106137-4
17 133110
18 726349
19 48611
20 33004
21 130237
22 50509
23b 030352W
24 40408
26c 039300W
27 66164
28 020003W
29 030019W
30 531011
49 727201
50 039301W
51 039302W
52 30374
53 25066
54 726603
55 412432
56 726494
57 726616
58 412431
Qty Welch Allyn Part Number Description
1 BASE WELDMENT 6002/6502 SCALE-T
6 FOOT PLASTIC I 3/4" X 3/8"
6 SCW, 1/4-20 X 5/8", HEX, BUTTON HEAD, SS
2 WHEEL 4"
2 BUSHING, WHEEL 5/16" X 1"
2 SCW 5-16-24X1 3/4 HEX CS GRD 8,NICK
2 NUT,5/16-24 HEX NKL
1 HARNESS INTERIOR BASE LONG SCALE-T
4 SCREW 4-40 x .380 PAN PHILLIPS
1 CABLE GUARD
35 10-32 X 1/4 SCREW - BHMS SOC
1 CLIP, METAL CABLE 3/16"
1 BOTTOM PAN 5002, SCALE-T
4 PLATE, OVERLOAD PROTECT, 500LB-DWB
4 LOAD CELL 500 LB DWB-SCALE-T
8 NUT,10-32 EXTLOCK
4 MOUNT METAL LOAD
1 PCBA MEASUREMENT BOARD-SCALE-T
10 SCW, 6-32 X 1/4" PHMS SEMS, NICKEL
6 WSH 1/4 STEEL SPLIT LOCK
6 SCW 10-32X3/8 PHIL RND MS SS
4 1/8 THICK EAR SPACER 3/4" X 3/4"
1 PLATE 6002 GPR TOP
4 BHSCS 10-32 X 3/8 18-8 STAINLESS STEEL
1 PLATFORM DECK 6002 SN>4000
4 1/4-20 X 1/2 FLAT HD SOCK SCR
2 HINGE PIANO 6002 RAMP
2 RAMP 6002
2 SHUR-STEP GRAY 12"X9 3/4"(2 PCS)
1 MAST CASE, HIGH, WITH PRINTER, SCALE-T
1 HANDLE MAST GRAY
2 PIN ALIGNER MAST HANDLE
2 WASHER, 0.318" ID X 0.738" OD X 0.062 TK
2 BOLT. 1/4-20 X 1" HEX HEAD, SS
1 HARNESS INTERIOR MAST COMMON SCALE-T
1 HARNESS POWER JACK DC 2.5MM SCALE-T
2 SCREW 1/32X3/8 THREAD FORM
1 BRACKET, MAST, BATT HLD, SCALE-T
1 HARNESS BATT HOLDER W/GRD SCALE-T
