- Page 1 Welch Allyn Stow-A-Weigh Scales Directions for use Models 5202, 6202, 6202D...
- Page 2 © 2016 Welch Allyn. All rights are reserved. To support the intended use of the product described in this publication, the purchaser of the product is permitted to copy this publication, for internal distribution only, from the media provided by Welch Allyn. No other use, reproduction, or distribution of this publication, or any part of it, is permitted without written permission from Welch Allyn.
-
Page 3: Table Of Contents
Contents Introduction ..................... 1 Intended use ......................1 Indications for use ....................1 Symbols ....................... 1 About warnings and cautions ................2 Controls and indicators ..................4 Installation and setup ................7 Installation instructions ..................7 Custom setup ...................... 9 Scale operation .................. - Page 4 Contents Welch Allyn Stow-A-Weigh Scales...
-
Page 5: Introduction
Introduction Intended use The Welch Allyn Stow-A-Weigh Scales are intended to be used by clinicians for weighing patients up to 660 pounds (300 kg) for model 5202, up to 880 pounds (400 kg) for model 6202, and up to 1000 pounds (450 kg) for model 6202D. -
Page 6: About Warnings And Cautions
Caution statements can appear on the Welch Allyn Stow-A-Weigh Scales, the packaging, the shipping container, or in this Directions for use. The Welch Allyn Stow-A-Weigh Scales are safe for patients and clinicians when used in accordance with the instructions and caution statements presented in this Directions for use. - Page 7 Directions for use Introduction 3 General warnings and cautions WARNING Patient injury risk. Make sure the scale is properly cleaned between measurements. WARNING Patient or operator injury risk. Make sure the scale is positioned on a stable surface and in a way to avoid shock or bumping hazards.
-
Page 8: Controls And Indicators
4 Introduction Welch Allyn Stow-A-Weigh Scales Controls and indicators Scale Model 5202 Front panel Scale frame Weighing platform Mounting bracket Battery access door... - Page 9 Directions for use Introduction 5 Models 6202 and 6202D Front panel Scale frame Weighing platform Mounting bracket Battery access door Printer (optional) N/A Satellite platform for model 6202D...
- Page 10 6 Introduction Welch Allyn Stow-A-Weigh Scales Front panel buttons Button Function ZERO Press this button to reset the scale to zero. Press this button to turn on the scale. Press this button in conjunction with to enter the setup mode.
-
Page 11: Installation And Setup
Installation and setup Use the following instructions to install and setup your scale for use. Installation instructions The scale should be installed in a location with a flat, firm floor. It can be installed over dense, low height commercial carpeting without problem. When used with some thicker, looser carpet piles the weighing platform might not fold down squarely against the floor. - Page 12 4. Once the bracket is mounted, lift the scale and lower it into position on the lip of the bracket. Center the scale side to side in the bracket. Model 6202 with a 14-inch bracket CAUTION The mounting bracket serves only to retain the scale against the wall to keep it from tipping over.
-
Page 13: Custom Setup
Directions for use Installation and setup 9 Model 6202D with two 14-inch brackets CAUTION The mounting brackets serve only to retain the scale against the wall to keep it from tipping over. The mounting brackets should not support the scale and keep the scale frame from resting on the floor. 1. - Page 14 RECALL This option allows you to turn button functionality. rS-232 Detailed instructions for this feature are available from Welch Allyn. Go to http:// www.welchallyn.com/en/other/contact-us.html to find your local representative. OutPut* This option displays the current data port output option. Detailed instructions for this feature are available from Welch Allyn.
- Page 15 Directions for use Installation and setup 11 If the pounds indicator is illuminated, it will only print in pounds, regardless of the unit is selected on the control panel. PrtOPT* RECALL Press to choose between the following options: PnlPrt PRINT : The current weight is printed when is pressed on the control panel.
- Page 16 12 Installation and setup Welch Allyn Stow-A-Weigh Scales...
-
Page 17: Scale Operation
Scale operation Power options The scale can be used with battery power or with AC power. Battery power CAUTION Use only size D disposable alkaline batteries. The use of any other battery will void the warranty. Lower the weighing platform to power on the scale. The scale automatically turns off after 45 seconds of non-use when operating on battery power. -
Page 18: Weighing Procedure
14 Scale operation Welch Allyn Stow-A-Weigh Scales Four long The battery is too weak to operate the scale. beeps Four short The scale has entered setup mode. beeps Weighing procedure 1. Make sure that the scale platform is down. 2. If necessary, press ON to turn on the scale. -
Page 19: Storage, Cleaning, And Maintenance
Storage, cleaning, and maintenance Storage The scale's weighing platform should be stowed in its upright position when then scale is not in use. Cleaning 1. Clean the scale at least once per day. 2. Use one of the following products when cleaning your scale: 70 percent isopropyl alcohol ®... -
Page 20: Change The Printer Paper
16 Storage, cleaning, and maintenance Welch Allyn Stow-A-Weigh Scales Change the printer paper The printer is a purchasable option. 1. Use a screwdriver to loosen the screw on the battery access door and remove the printer access door. 2. Remove the spindle containing the empty printer paper roll from the printer paper well. -
Page 21: Maintenance
Directions for use Storage, cleaning, and maintenance 17 8. Install the printer access door, and advance the new paper through the slot on the door. 9. Install the screw on the printer access door. Maintenance Routinely perform the following preventive maintenance to keep your scale in working order. - Page 22 18 Storage, cleaning, and maintenance Welch Allyn Stow-A-Weigh Scales Issue Possible cause Suggested action r-FAIL The scale's memory has failed. Contact your service department. The error message displayed A-FAIL The scale's memory has failed Contact your service department. The error message...
-
Page 23: Appendices
Item Specification Scales 5202, 6202, 6202D Resolution (factory default) 5202, 6202: 0.1 lb. / 0.1 kg (100 g) 6202D: 0.5 lb. / 0.2 kg Weighing capacity 5202: 660 lb. (300 kg) 6202: 880 lb. (400 kg) 6202D: 1000 lb. (450 kg) Readout Large, bright light-emitting diode display. -
Page 24: Product Configurations
20 Appendices Welch Allyn Stow-A-Weigh Scales Product configurations The Welch Allyn Stow-A-Weigh Scales are available in the following configurations: Model 5202, Stow-A-Weigh Stand-On Scale Model Description 5202-K Stow-A-Weigh Stand-On Scale, kilogram only 5202-X Stow-A-Weigh Stand-On Scale, standard weight Model 6202, Stow-A-Weigh Wheelchair Scale... -
Page 25: Warranty
AC power adapter Warranty Welch Allyn will warranty the weight scale to be free of defects in material and workmanship and to perform in accordance with manufacturer specifications for the period of one year from the date of retail purchase. - Page 26 Material No. 724514...
