Disassembly and repair

These procedures provide instructions for device disassembly and board removal, as well as component
replacement and reassembly.
Each part's disassembly instructions might include one or both of the following:
Reassembly notes:
•
a minimum, these notes indicate whether reassembly is the reverse of disassembly.
The notes also list service kits of replacement parts where applicable.
When replacing the component:
•
related to installing a new option or replacement part.
Each disassembly step includes drawings that illustrate the components to be removed. The reassembly
notes could be as short as one or two lines when reassembly is the reverse of disassembly. When
reassembly is more complicated, these notes alert you to any special care required to complete the
repair or installation and sometimes introduce separate reassembly instructions. Line drawings appear
in the reassembly notes only when they differ from the drawings in the disassembly instructions.
Note: Whenever the scale is opened for repair purposes a Calibration must be performed.
This subsection contains information specific to reassembly. At
This subsection contains additional instructions
