130234 BOLT 3/8-16 X 3 3/4" HEX HEAD
130237 SCW 10-32X3/8" PHIL RND MS SS
131052 NUT 1/4-20 JAM
132074 WASHER 3/8" IDX1" ODSS
133086 LOADMOUNT 3/8" X 1" WITH 3/8"
133110 MOUNT METAL LOAD
726340 WSHR,0.281"ID,1.5" OD,0.11"- 0.14THK
726341 SHOULDER SCREW 1/2" OD X 1/4" L
726348 WASHER,1/4"IDX1"ODX0.060"-0.090"TH
726461 NUT, 1/4-20 SER FLNG, GR5 ZINC SCALE-T
726494 SCREW, 1-32 X 3/8, THREAD FORM
135
