Quantum Data 980 User Manual page 80

980 User Guide
Item
Add Data
Delete EDID Block
Delete Selected CEA Data
Block or Timing
Load EDID from PC file
Save EDID to PC
Set 980 EDID from PC file
Page 80
Item - Column
Create Block 0
Create Block 1
Create Block 2
Create Block 3
Insert CEA Block
Insert CEA Audio Data
Block
Insert CEA Video Data
Block
Insert CEA Vendor
Specific Data Block
Insert CEA Speaker
Allocation Data Block
Insert CEA Video
Capability Data Block
Insert CEA Vendor
Specific Video Data Block
Insert CEA Colorimetry
Data Block
Insert CEA Vendor
Specific Audio Data Block
Deletes a selected EDID block.
Deletes a selected CEC data block.
Loads an EDID from your PC into the EDID Management Editor.
Saves the EDID that you have created or modified using the EDID Management
Editor to the host PC.
Configures the 980 Rx port with the specified EDID.
Description
Enables you to add a new Block 0 to the EDID.
Enables you to add a new Block 1 to the EDID.
Enables you to add a new Block 2 to the EDID.
Enables you to add a new Block 3 to the EDID.
Enables you to add a new CEA extension block.
Enables you to add a new Audio Data Block to the
CEA extension block.
Enables you to add a new a new Video Data Block to
the CEA extension block.
Enables you to add a new a new Vendor Specific
Data Block to the CEA extension block.
Enables you to add a new a new Speaker Allocation
Data Block to the CEA extension block.
Enables you to add a new a new Video Capability
Data Block to the CEA extension block.
Enables you to add a new a new Vendor Specific
Video Data Block to the CEA extension block.
Enables you to add a new a new Colorimetry Data
Block to the CEA extension block.
Enables you to add a new a new Vendor Specific
Audio Data Block to the CEA extension block.
Rev. B29
August 5, 2011
