Line Statistics
Page 76
Item - Column
Hfreq (kHz)
Vtotal
Vactive
Pix Freq (MHz)
Hsync Width
Vsync (width)
Start Video Line
HToVDelay
Encryp Start Pixel
Encryp Pulse Line
Encryp Length
Frame
Line
Time Stamp
Duration
Htotal
TMDS HTotal
Hsync Width
Hback
HActive
Description
The rate that a line in a frame is rendered.
The total number of lines in the vertical frame.
The number of lines in the vertical resolution.
The pixel rate of the format.
The number of pixels in the horizontal sync pulse.
The number of lines in the vertical sync pulse.
The line that the active video begins on.
The delay in pixels between the horizontal and vertical sync
pulse.
The pixel in the line that the encryption enable pulse begins on.
The line that the encryption enable pulse occurs on.
The length of the encryption enable pulse in pixels.
The frame number in the captured data.
The number of a particular line in the frame.
Timestamp for the beginning of the frame. Provided in
nanoseconds in HH:MM:SS:ms:us:ns.
Example: 2:0:29:807:126:843
2 Hours; 0 Minutes; 29 seconds; 807 milliseconds; 126
microseconds; 843 nanoseconds.
The duration of the frame in nanoseconds. Same format as that
shown for Time Stamp above.
The total number of pixels in a line including blanking.
The total number of clock cycle in a line including blanking.
The number of pixels in the horizontal sync pulse.
Horizontal back porch delay.
The total number of pixels in the active video.
