NOTE

Error Codes

Hex
Error Type
Equivalent
X000
No Error
General
X200
Common
X201
Hardware
Error
X300
X301
X30B
Hardware
X30C
Specific
X30D
Error
X30E
X30F
X310
X400
X401
X402
X403
Module
X404
Specific
Configuration
X405
Error
X406
X407
X408
X409
Chapter 4: Diagnostics and Troubleshooting
If no errors are present in the module error field, the extended error
information field is set to zero.

4.6.3 Hardware Errors

General or module-specific hardware errors are indicated by module error code
001. See Extended Error Codes below.

4.6.4 Configuration Errors

If you set the fields in the configuration file to invalid or unsupported values, the
module generates a critical error.
The Extended Error Codes table lists the possible module-specific configuration
error codes defined for the modules.
The table below explains the extended error code.
Table 4-3. Extended Error Codes
Module
Extended Error
Error
Information Code
Code
(Binary)
000
0 0000 0000
001
0 0000 0000
001
0 0000 0001
001
1 0000 0000
001
1 0000 0001
001
1 0000 1011
001
1 0000 1100
001
1 0000 1101
001
1 0000 1110
001
1 0000 1111
001
1 0001 0000
010
0 0000 0000
010
0 0000 0001
010
0 0000 0010
010
0 0000 0011
010
0 0000 0100
010
0 0000 0101
010
0 0000 0110
010
0 0000 0111
010
0 0000 1000
010
0 0000 1001
(Binary)
No Errors
General Hardware error; no additional information
Power-up reset state
General Hardware Error (ASIC)
H/W ROM Error (Calibration Error)
Channel 0 ADC Error
Channel 1 ADC Error
Channel 2 ADC Error
Channel 3 ADC Error
Channel 4 ADC Error
Channel 5 ADC Error
General Config Error: no additional information
invalid input type selected ch0
invalid input type selected ch1
invalid input type selected ch2
invalid input type selected ch3
invalid input type selected ch4
invalid input type selected ch5
invalid input filter selected ch0
invalid input filter selected ch1
invalid input filter selected ch2
User's Manual Pub. 0300241-02 Rev. A
Error Description
4-5
