Appendix C: Configuring the IR6I for CompactLogix Controllers in RSLogix 5000
User's Manual Pub. 0300241-02 Rev. A
Your 1769sc-IR6I module input data is located in the following tag addresses
when the controller is in Run mode.
1769sc-IR6I Channel Tag Address
0
1
2
3
4
5
Where 1 represents the slot number of the 1769sc-IR6I module.
Local:1:I.Data[0]
Local:1:I.Data[1]
Local:1:I.Data[2]
Local:1:I.Data[3]
Local:1:I.Data[4]
Local:1:I.Data[5]
