Appendix B: Module Configuration Using MicroLogix 1500 and RSLogix 500
Configuring the
1769sc-IR6I in a
MicroLogix 1500
System
This example takes you through configuring your 1769sc-IR6I Isolated
RTD/Resistance input module with RSLogix 500 programming software,
assumes your module is installed as expansion I/O in a MicroLogix 1500 system,
and that RSLinx™ is properly configured and a communications link has been
established between the MicroLogix processor and RSLogix 500.
To configure the system:
1. Start RSLogix and create a MicroLogix 1500 application. The following
screen appears:
User's Manual Pub. 0300241-02 Rev. A
B-3
