Chapter 2: Installation and Wiring
User's Manual Pub. 0300241-02 Rev. A
Figure 2-3. Module Parts List
Item Description
1
Bus lever
2a
Upper panel mounting tab
2b
Lower panel mounting tab
3
Module status LED
4
Module door with terminal identification label
5a
Movable bus connector (bus interface) with female pins
5b
Stationary bus connector (bus interface) with male pins
6
Nameplate label
7a
Upper tongue-and-groove slots
7b
Lower tongue-and-groove slots
8a
Upper DIN rail latch
8b
Lower DIN rail latch
9
Write-on label for user identification tags
10
Removable terminal block (RTB) with finger-safe cover
10a
RTB upper retaining screw
10b
RTB lower retaining screw
11
CJC sensors
