Appendix C: Configuring the IR6I for CompactLogix Controllers in RSLogix 5000
6. Select Comm Format (Input Data – INT for the 1769sc-IR6I, and fill in
7. Next, select the slot number, although it will begin with the first
8. Enter the Comm Format, Assembly Instance, and Size values for the
Table C-1 (Generic Profile Settings)
1769 I/O
Module
IR6I
9. Enter the Assembly Instance numbers and their associated sizes for the
The following default Generic Profile dialog appears:
the Name field. For this example, IR6I is used to help identify the
module type in the Controller Organizer. The Description field is
optional and may be used to provide more details concerning this I/O
module in your application.
available slot number, 1, and increments automatically for each
subsequent Generic Profile you configure. For this example, the 1769sc-
IR6I Isolated RTD/resistance module is located in slot 1.
1769sc-IR6I RTD/resistance module using the following table:
Comm.
Format
Input Data - INT Input
1769sc-IR6I module into the Generic Profile.
Parameter Assembly
Instance
101
Output
104
Config.
102
User's Manual Pub. 0300241-02 Rev. A
C-3
Size
(16-Bit)
8
0
12
